| Osnovne karakteristike | | Tip | Active PFC | | ATX standard | ATX 12V Ver. 3.1 | | Snaga | 850 W | | Klasifikacija efikasnosti | 80 Plus Bronze | | Faktor snage | >0.9 | | Vrsta kablova | Polu modularni | | Sistemi zaštite | OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), SCP (Short-Circuit Protection), OPP (Over Power (Load) Protection), OTP (Over Temperature Protection), AFC (Automatic Fanspeed Control), SIP (Surge-Inrush Protection) |
|
| +12V naponske grane | | 1 | 70.8A | | Maksimalna kombinovana snaga | 850W |
|
| Ostale naponske grane | | +5V | 18A | | +3.3V | 18A | | Maksimalna kombinovana snaga | 100W |
|
| Fiksni priključci | | ATX 24pin | 24(20+4)pin | | ATX 8pin (EPS 12V) | 2x 8(4+4)pin | | PCI Express 8pin | 2x 8(6+2)pin | | SATA | 6 | | Molex 4pin | 3 | | Ostali priključci | 1x 16pin 12V (2x6) |
|
| Hlađenje | | Tip | Aktivno | | Broj ventilatora | 1 | | Dimenzije ventilatora | 120mm |
|
| Fizičke karakteristike | | Format | ATX | | Dimenzije | 150mm x 140mm x 86mm | | Masa | 1.9kg |
|
| Reklamacioni period | | Reklamacioni period | 24 meseca |
|
