| : Osnovne karakteristike | | Tip | : Active PFC | | ATX standard | : 12V v2.53 | | Snaga | : 650 W | | Klasifikacija efikasnosti | : 80 Plus Bronze | | Efikasnost | : ≥ 80% | | Faktor snage | : >0.9 | | Vrsta kablova | : Fiksni | | Sistemi zaštite | : OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), SCP (Short-Circuit Protection), OPP (Over Power (Load) Protection), OTP (Over Temperature Protection), AFC (Automatic Fanspeed Control), SIP (Surge-Inrush Protection) |
|
| : +12V naponske grane | | 1 | : 54.1A | | Maksimalna kombinovana snaga | : 650W |
|
| : Ostale naponske grane | | +5V | : 18A | | +3.3V | : 18A | | Maksimalna kombinovana snaga | : 100W |
|
| : Fiksni priključci | | ATX 24pin | : 24(20+4)pin | | ATX 8pin (EPS 12V) | : 2x (4+4)pin | | PCI Express 8pin | : 2x 8(6+2)pin | | SATA | : 6 | | Molex 4pin | : 2 |
|
| : Hlađenje | | Tip | : Aktivno | | Broj ventilatora | : 1 | | Dimenzije ventilatora | : 120mm | | Dodatne funkcije | : Tih ventilator |
|
| : Fizičke karakteristike | | Format | : ATX | | Dimenzije | : 150mm x 140mm x 86mm | | Masa | : 1.9kg |
|
| : Reklamacioni period | | Reklamacioni period | : 24 meseca |
|
